MERIT Verkfæri fyrir Hjallahamra
Verkfæri MERIT fyrir vökvaknúsara eru hönnuð til að skila hámarks frammistöðu, framúrskarandi slitþoli og hámarksendingu í krefjandi aðstæðum. Þau eru samhæfð við hamarakerfi #Epiroc, #Rammer, #Montabert, #Krupp og fleiri alþjóðleg vörumerki, og tryggja skilvirka orkuflutning og fullkomna vernd hamarsins.
Iðnaðargæði og háhrein málmblöndur
MERIT framleiðir verkfæri sín úr hágæða málmblöndum sem eru valdar fyrir mjög hátt hreinleikastig.
Þessi samsetning minnkar hættuna á sprungum, eykur hörkudýptina og tryggir yfirburðar vélræna stöðugleika.
Með háþróaðri hitameðferð okkar fær yfirborðið stjórnaða hörku á meðan kjarninn helst sveigjanlegur til að taka við beygjukröftum við högg.
Hagrædd orkuflutningur
Hvert MERIT-verkfæri er unnið með örfínni nákvæmni.
Fullkomlega slétt höggflöt gerir hamarkólfinum kleift að flytja 100% af kraftinum beint til bergsins.
Niðurstöður:
aukin afköst,
minnkað slit á kólfinum,
vernd fyrir strokki og neðri hluta hamarsins.
Breitt úrval fyrir allar notkunaraðstæður
MERIT býður upp á fullt úrval verkfæra:
keilulaga oddur,
pýramídaoddur,
meitill,
stubbur (pilon),
sérverkfæri (póstagötunartæki, „campana“, þjöppunartæki o.fl.).
Hvert verkfæri er hannað fyrir sérstakt notkunarsvið til að hámarka framleiðni og lækka rekstrarkostnað.
Reglufesta og gæðaeftirlit
Reglufesta í framleiðslu er einn helsti styrkleiki MERIT.
Hvert verkfæri er framleitt með sömu vinnsluaðferðum, sömu hitameðferð og sömu málþolum.
Þessi stöðugleiki tryggir endurtekna frammistöðu og fyrirsjáanlega endingu — mikilvægur kostur fyrir faglega notendur.
Krupp HM 1000 and HM 1000 Marathon
1. Working Tools (Outils à emmancher)
Page 3
| Part Number | Description (Original) | Description (English) |
| 3067143 | Pointerolle (outil universel) | Moil Point (Universal tool) |
| 3067145 | Burin plat, transversal | Flat Chisel (Crosscut) |
| 3067119 | Pilon (pétardage) | Blunt Tool (Ramming) |
| 3066065 | Graisse spéciale Krupp (500 g) | Special Krupp Grease (500g Cartridge) |
2. Main Percussion Unit (Marteau Hydraulique)
Page 4
| Part Number | Description (Original) | Description (English) |
| 3033001 | Marteau hydraulique HM 1000 | Hydraulic Breaker HM 1000 |
| 3066178 | Marteau hydraulique HM 1000 Marathon | Hydraulic Breaker HM 1000 Marathon |
| 3033003 | Culasse de cylindre complète (31 cpl.) | Cylinder Head Complete |
| 3067047 | Douille d’étanchéité complète (41 cpl.) | Sealing Bush Complete |
| 3066027 | Cylindre | Cylinder |
| 3033049 | Piston de frappe | Percussion Piston |
| 3070038 | Partie inférieure du marteau (Marathon) | Lower Breaker Part (Marathon) |
| 3070037 | Partie inférieure du marteau (Standard) | Lower Breaker Part (Standard) |
| 3034294 | Tirant cpl. | Tie Rod Complete / Through Bolt |
| 0478171 | Joint torique | O-Ring |
| 3067187 | Rondelle | Washer |
| 3033051 | Douille de centrage | Centering Bush |
| 1850519 | Accumulateur de pression | High Pressure Accumulator |
| 1031912 | Joint torique | O-Ring |
| 1850529 | Bague d’appui | Back-up Ring |
| 1333703 | Rondelle d’arrêt | Lock Washer |
| 0026648 | Vis à tête cylindrique | Socket Head Screw |
| 0996719 | Soupape de remplissage cpl. | Filling Valve Complete |
| 0175125 | Joint torique | O-Ring |
| 2328126 | Joint torique | O-Ring |
| 2263820 | Bague à rainures | U-Packing / Grooved Ring |
| 2267557 | Joint en U à lèvres | Buffer Seal / U-Seal |
| 2267558 | Racleur | Wiper / Dust Seal |
| 1854657 | Vis de raccordement | Connection Screw |
| 0433774 | Graisseur conique | Grease Nipple |
| 1031794 | Bouchon fileté | Threaded Plug |
| 2267584 | Bague d’étanchéité | Seal Ring |
| 2267589 | Bague d’étanchéité | Seal Ring |
| 0478169 | Joint torique | O-Ring |
| 3031859 | Bague d’appui | Back-up Ring |
| 3033029 | Couvercle | Cover |
| 1331555 | Vis à tête cylindrique | Socket Head Screw |
| 0103776 | Bouchon vissé | Screw Plug |
| 0314375 | Joint torique | O-Ring |
| 3035425 | Douille d’étanchéité | Sealing Bush |
| 3067325 | Bague section carrée | Square Ring |
| 0107881 | Joint torique | O-Ring |
| 0314370 | Bague d’étanchéité | Seal Ring |
| 3035453 | Soupape complète | Control Valve Complete |
| 3067117 | Tiroir de pilotage | Control Spool |
| 3031872 | Douille de retenue | Retaining Bush |
| 0479721 | Axe de retenue | Retaining Pin |
| 3031973 | Douille de retenue | Retaining Bush |
| 2263821 | Bouchon | Plug |
| 0478426 | Bouchon fileté | Threaded Plug |
| 1031529 | Insert fileté | Threaded Insert |
| 1031946 | Insert fileté | Threaded Insert |
| 1031989 | Insert fileté | Threaded Insert |
| 1844113 | Disque filtrant | Filter Disc |
| 1844115 | Bouchon vissé | Screw Plug |
| 0206598 | Anneau à vis | Screw Ring / Lifting Eye |
| 3068027 | Bague d’impact | Impact Ring |
| 3031774 | Insert fileté | Threaded Insert |
| 3069195 | Douille d’usure (DustProtector) | Wear Bush (DustProtector) |
| 3069193 | Douille d’usure | Wear Bush |
| 0106074 | Vis à tête cylindrique | Socket Head Screw |
| 2261563 | Rondelle d’arrêt | Lock Washer |
| 0314372 | Joint torique | O-Ring |
| 1353488 | Bouchon fileté | Threaded Plug |
| 3069191 | Douille d’usure | Wear Bush |
| 3066028 | Coiffe anti-poussière | Dust Cap |
| 3066069 | Racleur de l’outil | Tool Wiper |
| 2261647 | Membrane cpl. | Diaphragm Complete |
| 3034311 | Jeu de joints | Seal Kit |
3. Hammer Box / Casing (Caisson du marteau)
Pages 5 & 7
| Part Number | Description (Original) | Description (English) |
| 3070010 | Caisson complet (Marathon) | Hammer Box Complete (Marathon) |
| 3070011 | Caisson complet (Standard) | Hammer Box Complete (Standard) |
| 3033467 | Elément amortisseur | Damping Element / Upper Cushion |
| 3033465 | Amortisseur | Shock Absorber / Buffer |
| 3035795 | Plaque | Plate |
| 3035793 | Plaque de guidage | Guide Plate |
| 3035773 | Bague libre | Floating Ring |
| 3035775 | Contre-bague | Counter Ring |
| 3035777 | Bague de guidage | Guide Ring |
| 3066048 | Bague anti-poussière | Dust Ring |
| 3033027 | Axe de retenue | Retaining Pin |
| 3033043 | Douille de retenue | Retaining Bush |
| 2262093 | Sécurité de transport | Transport Safety Device |
| 0026883 | Vis à tête cylindrique | Socket Head Screw |
| 1850747 | Rondelle d’arrêt | Lock Washer |
| 0103254 | Ecrou hexagonal | Hex Nut |
| 3070182 | Plaquette CE | CE Plate |
| 3066074 | Jeu de pièces en plastique (Marathon) | Plastic Parts Kit (Marathon) |
| 3066502 | Jeu de pièces en plastique (Standard) | Plastic Parts Kit (Standard) |
| 3033551 | Coiffe (ouverture de visite) | Cover (Inspection Opening) |
| 2267894 | Bouchon | Plug |
| 2267898 | Bouchon | Plug |
4. Lubrication & Connections (Graissage / ContiLube)
Pages 6 & 8
| Part Number | Description (Original) | Description (English) |
| 3068939 | Plaque | Plate |
| 0103750 | Boulon à tête cylindrique | Socket Head Bolt |
| 1850596 | Rondelle de retenue | Retaining Washer / Lock Washer |
| 2269857 | Adapteur pour agent lubrifiant | Lubricant Adapter |
| 3066233 | Raccord fileté orientable | Swivel Fitting |
| 3066231 | Conduite de graisse | Grease Line |
| 3066887 | Raccord-union | Union Fitting |
| 3068745 | Raccord-union | Union Fitting |
| 3066227 | Raccord fileté orientable | Swivel Fitting |
| 3066051 | Tuyau hydraulique | Hydraulic Hose |
| 3066951 | Bague d’étanchéité | Seal Ring |
| 3068937 | Plaque pour ContiLube® II | Plate for ContiLube II |
| 3066234 | Raccord fileté orientable | Swivel Fitting |
