| OEM Number | 3362 2605 45, 3362260545, 3362-2605-45 |
|---|---|
| Compatible With | Epiroc HB7000, Atlas Copco HB 7000 |
| Stock | Call Us |
| Qualität | OEM |
| Dimension | HB7000 |
Disclaimer:
All brands, references, and models mentioned—such as Epiroc, Rammer, Sandvik, Atlas Copco, Krupp, Montabert, Caterpillar, NPK, and others—are used solely for reference and compatibility purposes. MERIT is not an authorized dealer nor affiliated with these manufacturers.
All listed parts are aftermarket replacement components, OEM-equivalent, produced by independent manufacturers.
Specifications, availability, and compatibility information are subject to change without notice.
HB5800
3363 0860 37 — Elastic Pad
3363 0860 39 — Shock Absorber
3363 0860 41 — Guide Plate
3362 2652 15 — Guide Plate
3362 2626 67 — Guide Plate
3363 0933 85 — Plate
HB7000
3362 2696 97 — Guide Plate
3362 2626 67 — Guide Plate
3362 2626 65 — Guide Plate
3363 0933 83 — Plate
| 零件号/套件号 | 零件/套件名称 | 零件编号 |
|---|---|---|
| 整机型号 | Hydraulic breaker HB 7000 with lower wear bush (steel) | 3363120920 |
| 整机型号 | Hydraulic breaker HB 7000 with lower wear bush (bronze) | 3363121277 |
| 整机型号 | Hydraulic breaker HB 7000 DP with lower wear bush (steel) | 3363120949 |
| 整机型号 | Hydraulic breaker HB 7000 DP with lower wear bush (bronze) | 3363121278 |
| 整机型号 | Hydraulic breaker HB 7000 with lower wear bush (steel) with HATCON | 3363124802 |
| 整机型号 | Hydraulic breaker HB 7000 with lower wear bush (bronze) with HATCON | 3363124803 |
| 整机型号 | Hydraulic breaker HB 7000 DP with lower wear bush (steel) with HATCON | 3363124804 |
| 整机型号 | Hydraulic breaker HB 7000 DP with lower wear bush (bronze) with HATCON | 3363124805 |
| 套件 | Label kit HB 7000 | 3363121380 |
| 套件 | Seal kit | 3363121225 |
| 套件 | Seal kit for swivel joint for automatic lubrication system | 3363091732 |
| 套件 | Plastic parts kit | 3363089517 |
| 套件 | Tensioning bolt kit | 3363094355 |
| 套件 | DustProtector kit | 3363094391 |
| 套件 | Noise protection kit | 3363119327 |
| 套件 | Lower breaker part kit (steel) | 3363103412 |
| 套件 | Lower breaker part kit (bronze) | 3363094381 |
| 套件 | Lower breaker part kit (steel) for DustProtector version | 3363103413 |
| 套件 | Lower breaker part kit (bronze) for DustProtector version | 3363094382 |
| 套件 | Fastening screw kit | 3363103487 |
| 套件 | Accumulator repair kit | 3363089850 |
二、机械零件（Mechanical Parts）
HB 7000 通用零件
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 2 | Elastic pad | 3362260549 |
| 3 | Shock absorber | 3362260545 |
| 4 | Guide plate | 3362269697 |
| 5 | Guide plate | 3362262667 |
| 6 | Guide plate | 3362262665 |
| 7 | Plate | 3363093383 |
| 11 | Floating ring (tribolid) | 3363070666 |
| 12 | Counter ring | 3363035643 |
| 13 | Guide ring | 3363035639 |
| 14 | Bolt | 3363070645 |
| 15 | Locking bush | 3361854363 |
| 18 | Base for wiper | 3363088649 |
| 19 | Wiper | 3363034589 |
| 20(21-24) | Transport safety device complete | 3363083677 |
| 22 | Allen screw | 3360114151 |
| 23 | Label transport safety device | 3363091872 |
| 24 | Nut | 3360103255 |
| 31 | Cover | 3363031181 |
| 32 | Plug | 3363086017 |
| 33 | Plate | 3363098852 |
| 34 | Allen screw | 3360103768 |
| 35 | Pair of lock washers | 3361333703 |
| 36 | Allen screw | 3360103750 |
| 37 | Pair of lock washers | 3361850596 |
| 38 | Plate | 3363098838 |
| 39 | Cover | 3363092697 |
| 40 | Plate | 3363106729 |
| 41 | Swivel joint cover | 3363111477 |
| 42 | Swivel joint cover | 3363111461 |
| 43 | Pair of lock washers | 3363111296 |
| 44 | Allen screw | 3360103751 |
| 95 | Lifting eye | 3363111996 |
| 96 | Protective plug HATCON | 3315439145 |
| 99 | Breaker box (HB 7000) | 3363106730 |
| 98 | Breaker box (HB 7000 DP) | 3363106726 |
| 500 | Automatic lubrication system | 3363067123 |
三、冲击单元（Percussion Unit）
Part 1: Cylinder Cover
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 100 | Cylinder cover | 3363121010 |
| 101 | Main control valve | 3363086519 |
| 102 | Cover | 3363086515 |
| 103 | O-ring | 3360314376 |
| 104 | Allen screw | 3360026784 |
| 105 | Pair of lock washers | 3361850748 |
| 106 | Valve (AutoControl) | 3363035453 |
| 107 | Threaded plug | 3363035425 |
| 108 | O-ring | 3360314370 |
| 109 | Safety valve (PowerAdapt) | 3363085270 |
| 110 | Threaded plug | 3363087086 |
| 111 | Threaded plug | 3363087087 |
| 112 | Seal | 3363123253 |
| 114 | Connecting screw | 3361854657 |
| 115 | O-ring | 3360478171 |
| 130 | Non-return valve | 3361854511 |
| 138 | O-ring | 3360314373 |
| 139 | Allen screw | 3360026513 |
| 140(141-149) | Swivel joint complete | 3363116889 |
| 141(142-143) | Adapter complete | 3363116887 |
| 143 | Snapping | 3363116062 |
| 144 | Adapter | 3363086569 |
| 145(146-147) | Seal kit | 3361850422 |
| 148 | Disk | 3361356645 |
| 149 | Cap | 3363083749 |
| 150(151-159) | Swivel joint complete | 3363116888 |
| 151(152-153) | Adapter complete | 3363116887 |
| 153 | Snapping | 3363116062 |
| 154 | Adapter | 3361356643 |
| 155(156-157) | Seal kit | 3361850422 |
| 158 | Disk | 3361356645 |
| 159 | Cap | 3361353489 |
| 160 | HP-accumulator | 3363094981 |
| 161 | Fastening screw | 3363113101 |
| 162 | Service kit O-rings | 3363114730 |
| 163 | Washer | 3363100049 |
| 164 | O-ring | 3360314364 |
| 165 | Back-up ring | 3360328046 |
| 170 | Strainer disk | 3361844113 |
| 171 | Threaded plug | 3361844115 |
| 172 | Threaded insert | 3361031546 |
| 173 | Threaded insert | 3361031529 |
| 174 | Flange | 3363104787 |
| 175 | Allen screw | 3360103750 |
| 180(181-183) | Filling valve complete | 3363087286 |
| 182 | Threaded plug | 3360478426 |
| 183 | O-ring | 3360175125 |
| 190(191-192) | Tensioning bolt complete | 3363085625 |
| 192 | Washer | 3363093655 |
| 195 | Valve (IPS – Intelligent Protection System) | 3363120683 |
| 196 | Seal | 3363121175 |
| 197 | Back-up ring | 3363121176 |
| 198 | O-ring | 3360314453 |
Part 2: Cylinder
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 200 | Seal flange | 3363120917 |
| 203 | Seal | 3363103419 |
| 204 | O-ring | 3360314455 |
| 205 | O-ring | 3360314368 |
| 206 | O-ring | 3360478097 |
| 207 | O-ring | 3361031988 |
| 290(291-292) | Seal kit | 3362268907 |
| 300 | Cylinder | 3363121022 |
| 305 | Wiper | 3363083672 |
| 350 | Percussion piston | 3363087006 |
| 370 | Lock pin | 3360106819 |
| 390(391-392) | Seal kit | 3362268905 |
Part 3: Lower Breaker Part
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 401 | Retainer bar | 3362260429 |
| 405 | Bolt | 3362260431 |
| 407 | Lock pin | 3360106818 |
| 409 | Plug | 3362260435 |
| 410 | Protective cap | 3361855719 |
| 411 | O-ring | 3360314453 |
| 480(481-488) | Lower breaker part complete (steel) | 3363089500 |
| 480(481-488) | Lower breaker part complete (bronze) | 3363116925 |
| 482 | Impact ring | 3363069085 |
| 483 | Wear bush | 3363069507 |
| 484 | Wear bush (steel) | 3363088657 |
| 484 | Wear bush (bronze) | 3363088513 |
| 485 | Bolt | 3362260431 |
| 486 | Locking bush | 3362260433 |
| 487 | Threaded insert | 3363085499 |
| 488 | Plug | 3363086301 |
四、连接与润滑系统
Connecting Kit for Automatic Lubrication System
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 551 | Support | 3363118844 |
| 554 | Allen screw | 3360026512 |
| 555 | Allen screw | 3360100796 |
| 556 | Pair of lock washers | 3361850596 |
| 557 | Pair of lock washers | 3361333703 |
| 560(561-569) | Connecting kit for automatic lubrication system | 3363119350 |
| 561 | Hydraulic hose (Oil line) | 3363083877 |
| 562 | Hydraulic hose (Grease line) | 3363087583 |
| 563 | Seal | 3362267584 |
| 566 | Fitting | 3363087185 |
| 567 | Fitting | 3363066234 |
| 568 | Fitting | 3363087186 |
| 569 | Fitting | 3363066233 |
| 575 | Plug | 3360107879 |
HATCON System
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 580(581-587) | HATCON (套件，件号见可选设备) | – |
| 581 | Tracking module HATCON | – |
| 582 | Damper HATCON | 3315439130 |
| 583 | Housing type 1 HATCON | 3315439110 |
| 584 | Lock ring HATCON | 3315439140 |
| 585 | Sleeve HATCON | 3315439120 |
| 586 | Product label HATCON | 3315439100 |
| 587 | Screw HATCON | 3315442800 |
五、可选零件（Optional Parts）
| 零件号 | 零件名称 | 零件编号 |
|---|---|---|
| 11 | Floating ring (steel) | 3363035641 |
| 500 | Automatic lubrication system HD | 3363117931 |
六、液压软管（Hydraulic Hoses）
| 零件编号 | 零件名称 |
|---|---|
| 3361853860 | Hydraulic hose, I.D. 32, JIC 1 5/8″, length 2800 mm (Return line) |
| 3363083563 | Hydraulic hose, I.D. 40, JIC 1 7/8″, length 2800 mm (Return line) |
| 3361853861 | Hydraulic hose, I.D. 32, JIC 1 5/8″, length 3500 mm (Return line) |
| 3363083562 | Hydraulic hose, I.D. 40, JIC 1 7/8″, length 3500 mm (Return line) |
七、可选设备（Optional Equipment）
| 零件编号 | 零件名称 |
|---|---|
| 3363122356 | Bio chisel paste cartridge, 12 x 550 g |
| 3363091200 | Chisel paste cartridge, 12 x 500 g |
| 3363034567 | GREASE PUMP |
| 3360433774 | Grease nipple |
| 3363089845 | Maintenance and charging box with nitrogen cylinder |
| 3363094940 | Maintenance and charging box without nitrogen cylinder |
| 3362235295 | Test gauge lower wear bush |
| 3363094952 | Inside callipers upper wear bush |
| 3363093497 | Base plate with threaded inserts |
| 3363087305 | Bolt kit |
| 3363102875 | Base plate with through borings |
| 3363094577 | Bolt kit |
| 3360478949 | Allen key (27 mm) |
| 3363103077 | Adapter kit for underwater applications |
| 3315442500 | Retrofit kit HATCON |
| 3315439105 | Security bit HATCON |
| 3315439106 | Magnet HATCON |
| 3363092991 | Piston retainer |
八、工作工具（Working Tools）
ClassicLine HB 7000 & DP
| 零件编号 | 工具名称 |
|---|---|
| 3363119563 | Moll point |
| 3363119564 | Chisel (cross) |
| 3363119565 | Chisel (parallel) |
| 3363119566 | Blunt tool |
ProLine HB 7000 & DP
| 零件编号 | 工具名称 |
|---|---|
| 3363118329 | Moll point |
| 3363118333 | Chisel (cross) |
| 3363091425 | Blunt tool |
