Epiroc EC150T Piston – Part No. 3363112401 | SAE 4340 Steel | 850mm
Premium replacement piston for the Epiroc EC150T hydraulic breaker. Manufactured from SAE 4340 alloy steel for maximum durability and impact resistance. Length: 850mm. Backed by a 1-year warranty. Genuine quality, fast delivery. Order now for reliable performance on your heavy equipment.
Epiroc EC150T Hydraulic Breaker Spare Parts – Complete Parts List
Essential Service & Repair Kits for Epiroc EC150T
Designed for routine maintenance and comprehensive repairs of the Epiroc EC150T hydraulic breaker:
- 3363112842 – Seal Kit
- 3363083589 – Seal Kit
- 3363083590 – Seal Kit
- 3363098088 – Fastening Screw Kit
- 3363089849 – Accumulator Repair Kit
- 3363121471 – Label Kit
Epiroc EC150T Percussion Unit – Part 1: Cylinder Cover Components
Critical components for the upper section of the Epiroc EC150T breaker:
- 3363112739 – Cylinder Cover
- 3363035439 – Main Control Valve
- 3361331555 – Cover
- 3360314375 – O-Ring
- 3360103776 – Allen Screw
- 3361854657 – Connecting Screw
- 3360478171 – O-Ring
- 3360478439 – Threaded Plug
- 3361854511 – Non-Return Valve
- 3363034041 – Blind Flange
- 3360314372 – O-Ring
- 3363034274 – Allen Screw
- 3363069585 – HP-Accumulator
- 3363070490 – Allen Screw
- 3361333703 – Pair of Lock Washers
- 3361031912 – O-Ring
- 3361850529 – Back-Up Ring
- 3361031990 – O-Ring
- 3361844113 – Strainer Disk
- 3361844115 – Threaded Plug
- 3361031989 – Threaded Insert
- 3361031529 – Threaded Insert
- 3361031946 – Threaded Insert
- 3363066963 – Plug M14 x 1.5mm
- 3363087286 – Filling Valve Complete
- 3360478426 – Threaded Plug
- 3360175125 – O-Ring
- 3363106905 – Tensioning Bolt Complete
- 3363093649 – Washer
- 3363113244 – Valve (Stroke Control)
- 3363112659 – O-Ring
- 3360314656 – O-Ring
- 3363113246 – Threaded Plug
- 3363119005 – Plate
- 3361850743 – Pair of Lock Washers
- 3360103735 – Allen Screw
Epiroc EC150T Percussion Unit – Part 2: Cylinder & Piston Parts
Key internal mechanisms responsible for high-performance impact on the EC150T hydraulic breaker:
- 3363112392 – Seal Flange
- 3361855099 – Seal
- 3363112705 – Seal
- 3363112528 – Cylinder
- 3361031950 – O-Ring
- 3363083669 – Wiper
- 3362267281 – Seal
- 3362267585 – Seal
- 3362267582 – Stircomatic
- 3363112401 – Percussion Piston (SAE 4340 Steel | 850mm | 1-Year Warranty)
- 3362268185 – Lock Pin
Epiroc EC150T Percussion Unit – Part 3: Lower Breaker Parts
External protection and tool retention parts for the EC150T hydraulic breaker:
- 3360981927 – Retainer Bar
- 3361854347 – Bolt
- 3362261705 – Lock Pin
- 3362262925 – Plug
- 3360995340 – Protective Cap
- 3360478097 – O-Ring
- 3363106627 – Lower Breaker Part Complete
- 3363069079 – Impact Ring
- 3363105553 – Wear Bush
- 3361854363 – Locking Bush
- 3363085379 – Threaded Insert
- 3360433774 – Grease Nipple
Epiroc EC150T Main Body & Safety Hardware
- 3363105835 – Elastic Pad
- 3363105837 – Shock Absorber
- 3363115362 – Guide Plate
- 3363115363 – Guide Plate
- 3363083343 – Transport Safety Device Complete
- 3360026883 – Allen Screw
- 3363091872 – Label Transport Safety Device
- 3360103254 – Nut
- 3363116067 – Cover
- 3363116113 – Cover
- 3363086011 – Plug
- 3363086015 – Plug
- 3362267893 – Plug
- 3363111994 – Lifting Eye
- 3315439145 – Protective Plug HATCON
- 3363116075 – Breaker Box
Epiroc HATCON – Hydraulic Attachment Tools Connectivity
Smart tracking and monitoring components for the Epiroc EC150T:
- 3315439130 – Damper HATCON
- 3315439110 – Housing Type 1 HATCON
- 3315439140 – Lock Ring HATCON
- 3315439120 – Sleeve HATCON
- 3315439100 – Product Label HATCON
- 3315442600 – Screw HATCON
- 3315442500 – Retrofit Kit HATCON
- 3315439105 – Security Bit HATCON
- 3315439106 – Magnet HATCON
Epiroc EC150T Hydraulic Hoses & Optional Equipment
- 3363087015 – Hydraulic Hose with Flange (2300mm / 91 in.)
- 3363087016 – Hydraulic Hose with Flange (2800mm / 110 in.)
- 3360106074 – Allen Screw
- 3363089476 – Seal
- 3363122356 – Bio Chisel Paste Cartridge
- 3363091200 – Chisel Paste Cartridge
- 3363034567 – Grease Pump
- 3363491004 – Charging Box (with Nitrogen Cylinder)
- 3363117786 – Charging Box (without Nitrogen Cylinder)
- 3361852171 – Test Gauge Lower Wear Bush
- 3363094952 – Inside Callipers Upper Wear Bush
- 3363099795 – Base Plate with Threaded Inserts
- 3363087303 – Bolt Kit
- 3363100699 – Base Plate with Through Borings
- 3363094575 – Bolt Kit
- 3360209445 – Allen Key (22mm)
- 3363117805 – Automatic Lubrication System Kit
Epiroc EC150T Working Tools – ClassicLine
Interchangeable demolition tools compatible with the Epiroc EC150T hydraulic breaker:
- 3363119609 – Moil Point
- 3363119610 – Chisel (Cross)
- 3363119611 – Chisel (Parallel)
- 3363119612 – Blunt Tool
