Rammer 162442 Cylinder 3288

🇵🇱 Rammer 162442 – Cylinder 3288 | Wysoka Jakość • Gotowe do Wysyłki

Oferujemy Cylinder Rammer 162442 (model 3288) – precyzyjnie obrobiony, wykonany z wysokowytrzymałej stali i gotowy do pracy w najcięższych warunkach.

🔧 Specyfikacja techniczna

• Długość: 27.44 in

• Średnica: 10.43 in

• Waga: 414.5 lbs

✔️ Zalety produktu

• Kompatybilny z młotami hydraulicznymi Rammer

• Obróbka CNC i kontrola jakości na każdym etapie

• Bardzo wysoka odporność na zużycie

• Produkt dostępny w profesjonalnej produkcji MERIT

• Szybka dostawa na cały świat

📦 Dostępność

✔️ Towar dostępny
✔️ Certyfikat pochodzenia na życzenie
✔️ Wysyłka międzynarodowa

Kontakt:
🌐 meritautomotive.com
📧 info@meritautomotive.com

Zastrzeżenie:
MERIT jest niezależnym producentem i dostawcą zamiennych części do młotów hydraulicznych. Nie jesteśmy powiązani, autoryzowani ani zatwierdzeni przez Rammer, Sandvik ani jakiegokolwiek innego producenta oryginalnego sprzętu (OEM). Wszelkie odniesienia do nazw Rammer, modeli, numerów części i znaków towarowych służą wyłącznie celom identyfikacji i określenia kompatybilności. Oferowane przez nas produkty są częściami wyprodukowanymi przez MERIT, a nie oryginalnymi częściami OEM.

Rammer 3288 parts list:

---

HOUSING UNIT HEAVY DUTY

1. Housing – 168089
   2.1 Pad – 155438
   3.1 Buffer – 154317 (Standard)
   3.2 Buffer – 168203 (Heavy duty)

2. Plug – 157947

3. Hex. screw – 90589

4. Washer – 90511

5. Lock nut – 90507

6. Shield plate – 163556

7. Plug – 158147

8. Plug – 400491

9. Plug – 953291

10. Wear plate – 163355

11. Lifting eye – 90705

12. Hex. screw – 900026

13. Seal – 153013

14. Wear parts – 168211
    Label set – 170436
    201.1 Safety label set – 169400

HOUSING UNIT HEAVY DUTY HARD ROCK

1. Housing – 168085
   2.1 Pad – 155438
   3.1 Buffer – 154317 (Standard)
   3.2 Buffer – 168203 (Heavy duty)

2. Plug – 157947

3. Hex. screw – 90589

4. Washer – 90511

5. Lock nut – 90507

6. Plug – 158147

7. Plug – 400491

8. Plug – 953291

9. Seal – 153013

10. Wear plate – 162598

11. Wear plate – 162597

12. Shield plate – 163556

13. Lifting eye – 90705

14. Hex. screw – 900026

15. Wear parts – 160399
    Label set – 170436
    201.1 Safety label set – 169400

HOUSING UNIT HEAVY DUTY PRIMARY BREAKING

1. Housing – 168085

2. Pad – 155438

3. Buffer – 168203 (Heavy duty)

4. Plug – 157947

5. Hex. screw – 90589

6. Washer – 90511

7. Lock nut – 90507

8. Plug – 158147

9. Plug – 400491

10. Plug – 953291

11. Seal – 153013

12. Wear plate – 162598

13. Wear plate – 162597

14. Shield plate – 163556

15. Lifting eye – 90705

16. Hex. screw – 900026

17. Wear parts – 160399

18. Label set – 170436
    201.1 Safety label set – 169400

ACCUMULATOR

1. Accumulator – 155339

2. Accumulator bottom – 173741

3. Accumulator cover – 155342

4. Membrane – 173532

5. Accumulator screw – 40416

6. Filling plug – 40368

7. Shield plug – 154015

8. O-ring – 910006

9. Parallel pin – 90304

10. Usit-ring – 90056

11. Accumulator screw – 41335

12. Seal – 41357

13. O-ring – 910002

MAIN VALVE
11. Main valve bushing – 103802
12. Main spool – 162453
13. Spool – 101853
14. Spool – 40112
15. Cover – 101472
16. Cover – 101830
17. Seal – 902668
18. O-ring – 90005
19. Lock washer – 90597
20. Hex. screw – 90517

RAMVALVE

1. Ramvalve – 172210
   1.1 Cover – 172149
   1.2 Valve housing – 172211
   1.3 Spool – 171031
   1.4 Spring – 954342
   1.5 O-ring – 90017
   1.6 O-ring – 90031
   1.7 O-ring – 90007
   1.8 Shim plate – 954349 (S=1)
   1.9 Shim plate – 954348 (S=0.5)
   1.10 Seal – 954341

2. Lock washer – 90597

3. Hex. screw – 90517

PRESSURE CONTROL VALVE
2. Pressure control valve – 162450
201. Cover – 161413
202. Valve housing – 162451
203. Spool – 162452
204. Guide – 400688
205. Spool – 400690
206. O-ring – 90083
207. Spring – 90104
208. Seal – 41375
209. Spring guide – 161433
210.1 Shim plate – 174182 (S=0.75)
210.2 Shim plate – 41793 (S=1)
210.3 Shim plate – 41794 (S=0.5)
211. Seal – 41374
212. O-ring – 910018
213. Plug – 112512
4. Lock washer – 90597
5. Hex. screw – 90517

IDLE SELECTOR

1. Valve – 163445

2. Cover – 156729

3. Spool – 163446

4. Seal – 112835

5. O-ring – 90001

6. Pin – 156730

7. Spring – 951797

8. Flange plug – 90444

STROKE SELECTOR VALVE

1. Valve – 163445

2. Cover – 156729

3. Spool – 163446

4. Seal – 112835

5. O-ring – 90001

6. Pin – 156730

7. Spring – 951797

8. Flange plug – 90444

TIE RODS

1. Tie rod – 158327
   1.1 Vibration dampening element – 155555
   1.2 Cable tie – 952009

2. Lock plate – 101449

3. Rubber ring – 40586

BODY PARTS

1. Valve body – 162448
   1.2 Breather – 400662
   1.3 Flange plug – 90401
   1.4 Flange plug – 90403
   1.5 Flange plug – 90444
   1.6 Flange plug – 93203
   1.7 Nozzle – 159795

2. Cylinder – 162442

3. Piston – 162445

4. Seal carrier – 162446
   4.2 Breather – 101700
   4.22 O-ring – 901173
   4.3 Plug – 173557

5. Wiper – 901160

6. Seal – 955144

7. Seal – 150244

8. Wiper – 952657

9. Seal – 952033

10. Seal – 903325

11. Seal – 41140

12. O-ring – 901124

13. O-ring – 90076

14. Parallel pin – 90317

15. O-ring – 90046

16. O-ring – 952116

FRONT HEAD

1. Front head – 173679
   1.2 Hex. socket screw – 900051
   1.3 Lock washer – 90597

2. Thrust ring – 155467

3. O-ring – 90076

4. Upper tool bushing – 101414

5. Tool retaining pin – 153235

6. Ring – 153236

7. Wedge – 40110

8. O-ring – 90000

9. Retaining pin – 173680

10. Rubber ring – 173685

LOWER TOOL BUSHING

1. Lower tool bushing – 155206

TOOL

1. Chisel – 881

2. Moil point – 883

3. Blunt – 884

4. Pyramid – 883K3

5. Limestone Chisel – 881F3

6. Hard Rock Chisel – 881A2

7. Super Blunt – 884T2

SEAL SET
Kit: Seal set – 163428

1. O-ring – 910006

2. Usit-ring – 90056

3. Seal – 41357

4. O-ring – 910002

5. Seal – 112835

6. O-ring – 90001

7. O-ring – 90083

8. Seal – 41375

9. Seal – 41374

10. O-ring – 910018

11. Seal – 902668

12. O-ring – 90005

13. O-ring – 90031

14. O-ring – 90007

15. O-ring – 90076

16. O-ring – 90000

17. O-ring – 901173

18. Wiper – 901160

19. Seal – 955144

20. Seal – 150244

21. Wiper – 952657

22. Seal – 952033

23. Seal – 903325

24. Seal – 41140

25. O-ring – 901124

26. O-ring – 90046

27. O-ring – 952116

28. O-ring – 951293

29. O-ring – 90017

30. Seal – 954341

31. Rubber ring – 173685

SERVICE KIT
Kit: Service kit – K13288

1. Membrane – 173532

2. Tool retaining pin – 153235

3. Lower tool bushing – 155206

4. Seal set – 163428

SERVICE KIT 2A HEAVY DUTY
Kit: Service kit – K2A3288

1. Pad – 155438

2. Buffer – 154317

3. Wear plate – 163355

4. Upper tool bushing – 101414

SERVICE KIT 2B HEAVY DUTY HARD ROCK
Kit: Service kit – K2B3288

1. Pad – 155438

2. Buffer – 154317

3. Wear plate – 162598

4. Wear plate – 162597

5. Upper tool bushing – 101414

SERVICE KIT 2D HEAVY DUTY PRIMARY BREAKING
Kit: Service kit – K2D3288

1. Pad – 155438

2. Buffer – 168203

3. Wear plate – 162598

4. Wear plate – 162597

5. Upper tool bushing – 101414

GREASING BLOCK FOR MANUAL GREASING
Kit: Greasing block for manual greasing – 168833
2. Hose assembly – 168842
2.1 Hose – 953927
2.3 Sleeve – 153035
2.4 Insert – 153036
2.5 Nut – 951296
3. Connector – 951294
4. Body – 168824
5. Grease nipple – 90200
6. Hex. screw – 901542
7. Lock washer – 953503
8. Shield – 952093
9. Rubber bushing – 158147

GREASING DEVICE KIT
Kit: Greasing device retrofit kit – K60088

1. Greasing device RG542 – 953345

2. Hose assembly – 176785
   3.1 Sleeve – 153035
   3.2 Insert – 153036
   3.3 Hose – 951632
   3.4 Nut – 951296

3. Rubber bushing – 158147

4. Shield – 952093

5. Hex. screw – 953794

6. Lock washer – 953503

7. Grease cartridge – 951370

8. Shield – 168032

9. Hex. socket screw – 902895

10. Lock washer – 90597

11. Connector – 951295

12. Connector – 951294

13. Hose assembly – 955155

GREASING DEVICE

1. Greasing device RG542 – 953345

2. Doser – 173573
   2.1 Plug – 173574
   2.2 Nut – 953330
   2.3 Lock washer – 91038
   2.4 O-ring – 953325
   2.5 Adjusting screw – 953317
   2.6 O-ring – 953326
   2.7 O-ring – 953324
   2.8 Spring – 953331
   2.9 Piston – 173576
   2.10 O-ring – 953322
   2.11 Piston – 953329
   2.12 Body – 173575
   2.13 O-ring – 953323
   2.14 Shim plate – 953321

3. Grease nipple – 90200

4. Plug – 953303

5. Locking plate – 953302

6. Body – 953335

7. Cartridge holder – 953334

8. Check valve – 951767

9. O-ring – 951416

10. O-ring – 951453

11. O-ring – 953300

12. O-ring – 953301

13. Guide ring – 950272

14. Seal – 953299

15. Spring housing – 953308

16. Spring – 950257

17. Piston – 953307

18. Nut – 953306

19. Lock plate – 951410

20. Hex. socket screw – 951421

21. Connector – 951294
    Kit: Seal set for greasing device – 953385

SERVICE KIT FOR GREASING DEVICE RG540 SERIES
Kit: Service kit for greasing device – 953385

1. Lock plate – 951410

2. Plug – 953303

3. Guide ring – 950272

4. Seal – 953299

5. O-ring – 953300

6. O-ring – 951453

7. O-ring – 953301

8. O-ring – 951416

9. O-ring – 953326

10. O-ring – 953325

11. O-ring – 953324

12. O-ring – 953323

13. O-ring – 953322

14. Shim plate – 953321

15. Spring – 953331

16. Piston – 953329

17. Lock washer – 91038

18. Grease nipple – 90200

19. Locking plate – 953302

RAMDATA II SERVICE INDICATOR

1. Ramdata II service indicator – 159143
   1.2 Hex. socket screw – 91020
   1.3 Lock washer – 91011

TOOL BOX R2
Kit: Tool box R2 – 173748

1. Tool box – N/A

2. Grease gun – 90202

3. Tool grease – 902045

4. Grease cartridge – 951370

5. Puller – 150020

6. Combination spanner – N/A

7. Screwdriver – N/A

8. Flange plug – 90444

9. Flange plug – 90403

10. Grease nipple – 953767

11. Safety glasses – N/A

COUPLING SETS
26. Coupling set – 400587
1.1 Flange – 90531
1.2 O-ring – 90009
1.3 Hexagon socket screw – 90593

27. Coupling set – 400599
    1.1 Flange – 915069
    1.2 O-ring – 90009
    1.3 Hexagon socket screw – 90593

28. Coupling set – 400591
    1.1 Flange – 915055
    1.2 O-ring – 90009
    1.3 Hexagon socket screw – 90593

29. Coupling set – 400590
    1.1 Flange – 915071
    1.2 O-ring – 90009
    1.3 Hexagon socket screw – 90593

---
